- Outlet Connection: 2" MNPT
- Inlet Connection: 3" MNPT
- Application: Tanks (Full or Half Couplings)
- U. L., Closing Flow, LP (Horizontal) Liquid GPM / l/min: 260 / 984
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 25 PSIG / 1,7 bar Inlet: 50,650 / 1,434
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 100 PSIG / 6,9 bar Inlet: 86,350 / 2,445
- Differential Pressure PSID / bar d: 6.9 / 0,48
