- Outlet Connection: 2" MNPT
- Inlet Connection: 3" MNPT
- Application: Tanks (Full or Half Couplings)
- U. L., Closing Flow, LP (Horizontal) Liquid GPM / l/min: 165 / 625
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 25 PSIG / 1,7 bar Inlet: 32,800 / 929
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 100 PSIG / 6,9 bar Inlet: 55,950 / 1,584
- Differential Pressure PSID / bar d: 3.1 / 0,21
