- Outlet Connection: 2" MNPT X 1 1/4" FNPT
- Inlet Connection: 2" MNPT
- Application: Tanks (Full or Half Couplings)
- U. L., Closing Flow, LP (Horizontal) Liquid GPM / l/min: 105 / 397
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 25 PSIG / 1,7 bar Inlet: 18,800 / 532
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 100 PSIG / 6,9 bar Inlet: 32,000 / 906
- Differential Pressure PSID / bar d: 8.9 / 0,61
