- Outlet Connection: 1 1/2" FNPT
- Inlet Connection: 2 1/2" MNPT X1 1/2" FNPT
- Application: Tanks (Full or Half Couplings)
- U. L., Closing Flow, LP (Horizontal) Liquid GPM / l/min: 60 / 227
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 25 PSIG / 1,7 bar Inlet: 12,000 / 340
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 100 PSIG / 6,9 bar Inlet: 20,290 / 575
- Differential Pressure PSID / bar d: 5.2 / 0,35
