- Outlet Connection: 1" FNPT
- Inlet Connection: 1 1/2" MNPT X 1" FNPT
- Application: Tanks (Full or Half Couplings)
- U. L., Closing Flow, LP (Horizontal) Liquid GPM / l/min: 28 / 106
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 25 PSIG / 1,7 bar Inlet: 5,181 / 147
- U. L., Closing Flow, LP (Horizontal) Vapor SCFH / SCMH 100 PSIG / 6,9 bar Inlet: 8,806 / 249
- Differential Pressure PSID / bar d: 2.7 / 0,19
