- Propane Vaporization Capacity Gallons/ hr: 40
- Propane Vaporization Capacity Million BTU/hr: 3.64
- Connections Liquid Inlet: 3/4" FNPT
- Connections Vapor Outlet: 1" FNPT
Shipping Dimensions: Depth 21" Height 41" Width 22"
Shipping Weight: 155 Lbs.
40/40H Baffle Plate - 707880
40/40H Post 10.02 Base Assembly - 707856
40/40H Pre 10.02 Burner Manifold - Old Burner - 708110
40/40H Post 10.02 Burner Manifold w/ #69 Burner Jet Orifices - 707870
40/40H Post 10.02 Burner Tip Kit - #69 Orifices (Qty. 10) - 707744
40/40H Pre 10.02 Burner Tip Kit - Old Burner (Qty. 6) - 708102
40/40H Post 6.06 Capacity Control Valve - 1" Outlet - 708117
40/40H Post 10.02 Case Assembly w/ Door - New Burner - 707822
40/40H Pre 2009 Door Assembly w/ Black Paddle Latch - 707858
40/40H Door Latch - Black Paddle Style - 707782
40/40H Pre 10.02 Door Latch - Camlock - Old Burner - 707106
40/40H Drip Leg Kit - 707804
40/40H Post 10.02 Flue - New Burner - 708076
40/40H Pre 10.02 Flue - Old Burner - 707112
40/40H Heat Exchanger Support Spacer - 708104
40/40H Liquid Inlet Valve - 708116
40/40H Liquid Inlet Valve Orifice Kit - 707502
40/40H Pre 10.02 Master Rebuild Kit - Old Burner - 708410
40/40H Post 10.02 Master Rebuild Kit w/ #69 Burner Jet Orifices - 707848
40/40H Pilot Assembly w/ Thermocouple - 707675
40/40H Post 10.02 Pilot Orifice - 708132
40/40H Pre 10.02 Pilot Orifice - Old Burner - 707141
40/40H Piston - Capacity Control Valve 1" Outlet - 708114
40/40H Regulator - Burner Supply - 708152
40/40H Re-Igniter Electrode 9V DC - 707614
40/40H Re-Igniter Kit 110V AC Field Install - 707665
40/40H Re-Igniter Kit 9 VDC Field Install - Old Style - 707816
40/40H Re-Igniter Module 9V DC - Ignitor Module Only - 707618
40/40H Re-Igniter Switch 9V DC - Old Style Pushbutton - 707619
40/40H Re-Igniter Switch Boot Cover 9V DC - Old Style - 707626
40/40H Repair Kit - Liquid Inlet/Capacity Control Valve - 707670
40/40H Post 10.02 Repair Kit - New Burner - 707034
40/40H Pre 10.02 Repair Kit - Old Burner - 707002
40/40H Repair Kit - Pilot & Thermocouple - 707014
40/40H Strainer - 3/4" NPT - 707433
40/40H Strainer Kit - 3/4" Strainer & Magnetic Plug - 707688
40/40H Thermocouple - 707458
40/40H Thermostat w/ 9V DC Ignitor - 707453
40/40H Tubing - Burner Regulator Suppy Kit - 707524
40/40H Tubing - Burner Suppy Kit - 707840
40/40H Tubing - Capacity Control Kit - 707154
40/40H Tubing - Pilot Suppy Kit - 707842
40/40H Tubing - Replacement Kit - 707499
40/40H Tubing - Thermostat Suppy Kit - 707172
40/40H Vapor Outlet Reducer - 707114
40/40H Vent Cap Assembly - 707501
