- Propane Vaporization Capacity Gallons/ hr: 120
- Propane Vaporization Capacity Million BTU/hr: 10.92
- Connections Liquid Inlet: 3/4" FNPT
- Connections Vapor Outlet: 1" FNPT
Shipping Dimensions: Depth 21" Height 50" Width 22"
Shipping Weight: 275 Lbs.
120/60H Baffle Plate - 708031
120/60H Post 10.02 Base Assembly - 707912
120/60H Post 10.02 Burner Manifold Left w/ #69 Burner Jet Orifices - 707998
120/60H Post 10.02 Burner Manifold Right w/ #69 Burner Jet Orifices - 708000
120/60H Post 10.02 Burner Tip Kit - #69 Orifices (Qty. 10) - 707744
120/60H Post 6.06 Capacity Control Valve - 1" Outlet - 708117
120/60H Case Assembly w/ Door - 707846
120/60H Pre 2009 Door Assembly w/ Black Paddle Latch - 708092
120/60H Door Latch - Black Paddle Style - 707782
120/60H Pre 10.02 Door Latch - Camlock - Old Burner - 707106
120/60H Drip Leg Kit - 707804
120/60H Flue - Left Side - 707768
120/60H Flue - Right Side - 707731
120/60H Heat Exchanger Support Spacer - 708104
120/60H Liquid Inlet Valve - 708116
120/60H Liquid Inlet Valve Orifice Kit - 707502
120/60H Post 10.02 Master Rebuild Kit w/ #69 Burner Jet Orifices - 707666
120/60H Pilot Assembly w/ Thermocouple - New Burner - 707678
120/60H Post 10.02 Pilot Flame Guide - New Burner - 708030
120/60H Pilot Orifice - 707680
120/60H Piston - Capacity Control Valve 1" Outlet - 708114
120/60H Regulator - Burner Supply - 708152
120/60H Re-Igniter Electrode 9V DC - 707614
120/60H Re-Igniter Kit 110V AC Field Install - 707665
120/60H Re-Igniter Kit 9 VDC Field Install - Old Style - 707816
120/60H Re-Igniter Module 9V DC - Ignitor Module Only - 707618
120/60H Re-Igniter Switch 9V DC - Old Style Pushbutton - 707619
120/60H Re-Igniter Switch Boot Cover 9V DC - Old Style - 707626
120/60H Repair Kit - Liquid Inlet/Capacity Control Valve - 707670
120/60H Repair Kit - Pilot & Thermocouple - 707538
120/60H Strainer - 3/4" NPT - 707433
120/60H Strainer Kit - 3/4" Strainer & Magnetic Plug - 707688
120/60H Thermostat w/ 9V DC Ignitor - 707453
120/60H Tubing - Burner Manifold Connector Kit - 707164
120/60H Tubing - Burner Regulator Suppy Kit - 707524
120/60H Tubing - Burner Suppy Kit - 707840
120/60H Tubing - Capacity Control Kit - 707154
120/60H Tubing - Heat Exchanger Connector - 707161
120/60H Tubing - Pilot Suppy Kit - 707842
120/60H Tubing - Replacement Kit - 707499
120/60H Post 10.02 Tubing - Thermostat Suppy Kit - New Burner - 708001
120/60H Vapor Outlet Reducer - 707114
120/60H Vent Cap Assembly - 707501
