- Inlet: 1 1/2" FNPT
- Outlet: 1" FNPT
- Motor Specs: 2 HP Single Phase115/208/230 Volt 50/60 Hertz
- GPM Thru Meter: 23
Weight: 126 Lbs.
Service Fill Time 20# Cylinder: 10 to 20 Seconds
Service Fill Time 100# Cylinder: 1 1/2 Minutes
Pump & Motor.
C13 Bronze Impeller - 140556
C13 Case Clearance Shim (.002” Red) (Qty. As Req.) - 140560
C13 Case Clearance Shim (.003” Green) (Qty. As Req.) - 140561
C13 Case O-Ring - Buna-N - 140948
C13 Case O-Ring - Teflon® - 140966
C13 Hex Head Cap Screw (Qty. 8) - 140990
C13 Housing Adjustment Shim (.010”) (Qty. As Req.) - 140562
C13 Housing Adjustment Shim (.020”) (Qty. As Req.) - 140563
C13 Motor 2 HP Model 13 - 141182
C13 O-Ring - Buna-N - 140938
C13 O-Ring - Teflon® - 140965
C13 Seal Assembly - 140525
C13 Seal Housing - Steel (Non-Teflon® O-Rings) - 140558
C13 Socket Head Cap Screw - 3/8-16 X 7/8" (Qty. 8) - 140520
C13 Woodruff Key - Steel - 140677
