ME992M-16-260

Item Number154830
  • Tank Connection: 2" MNPT

  • Outlet Connection: 2" FNPT (2)

  • Actuation: Manual With MEP990-24

  • Liquid Closing Flow Value: 260 GPM

Intended for use on transport trucks and large storage tanks with 2” threaded connections in directional or bi-directional flow applications. Provides both manual shut-down and excess flow closing in the event of the piping being seperated from the valve. Can be equipped with manual latch, pneumatic or rotary actuator open/closing devices. All valve models are equipped with a breakaway feature in the cast body which permits the piping to shear off in the event of side impact, leaving the valve poppet intact and protecting the tank from catastrophic product loss. The tee body features an additional FNPT side discharge port. For liquid or vapor service applications.

Features:
• Durable ductile body with cadmium surface plating.
• All stainless internal component construction.
• One piece threaded packing gland.
• Precision machined hard coated stem.
• Fully retained nitrile seat disc.
• Largest variety of excess flow closing values.
• Roller cam actuation.
• Industry’s fastest bleed time.
• Removable data plate.
• Industry’s easiest valve to service.
• Standard construction utilizes nitrile seals.
• Available with Neoprene, Viton®, or Kalrez® seals.
• UL LISTED for LPG & NH3 service.
• RulonTM bearings on stem and stub shafts.

Kalrez® & Viton® are a registered Trademarks of DuPont Performance Elastomers.

ME992-16 Air Actuator - 150576

ME992-16 Rotary Actuator - 150582

ME992-16 Manual Latch Assembly - 153540

ME992-16 Cable Control Release w/50' Cable - 153545

ME992-16 Cable Control Release - Only - 153550

ME992-16 Stem Packing Gland Assembly - 153585

ME992-16 Stem Packing Repair Kit - 153580

ME992-16 Operating Lever - Standard - 153560

ME992-16 Excess Flow Spring - 100 GPM (Yellow) - 153635

ME992-16 Excess Flow Spring - 160 GPM (Green) - 153640

ME992-16 Excess Flow Spring - 260 GPM (Blue) - 153645

ME992-16 Seal Repair Kit - 153630

ME992-16 Viton Seal Repair Kit - 153612

ME992-16 Complete Rebuld Kit - 153625

ME992-16 Fusible Link - 153565
