- Connections Inlet X Outlet: 3" MNPT X3" FNPT
- Closing Flow GPM / l/min Propane * Half Coupling: 460 / 1,741
- Closing Flow GPM / l/min Propane * Full Coupling: 380 / 1,438
- Vapor Capacity SCFH / SCMH Propane * 25 psig / 1,7 bar Inlet: -----
- Vapor Capacity SCFH / SCMH Propane * 100 psig / 6,9 bar Inlet: -----
C477-24 Air Actuator - 122934
C477-24 Bleed Disc - Ethylene Propylene (EPDM) - 129320
C477-24 Bleed Disc - Kalrez® (FFKM) - 129318
C477-24 Bleed Disc - Neoprene (CR) - 129319
C477-24 Bleed Disc - Nitrile (NBR) - 129412
C477-24 Bleed Disc - Teflon® (PTFE) - 129316
C477-24 Bleed Disc - Viton® (FKM) - 129317
C477-24 Bleed Disc Retainer - Stainless Steel - 129410
C477-24 Bleed Disc Seat - Stainless Steel - 129411
C477-24 Body - Ductile Iron - 129401
C477-24 Bonnet Nut - Steel - 128688
C477-24 Bushing - Teflon® (PTFE) - 125800
C477-24 Cable Latch - 122912
C477-24 Cam - Stainless Steel - 129031
C477-24 Cam - Steel - 128694
C477-24 Cap Screw - Stainless Steel - 129032
C477-24 Cap Screw - Steel - 126282
C477-24 Cap Screw - Steel (Qty. 3) - 129063
C477-24 Closing Spring - Stainless Steel - 128646
C477-24 Cotter Pin - Stainless Steel - 129056
C477-24 Cotter Pin for Lever - 127092
C477-24 Disc Holder - Stainless Steel - 129230
C477-24 Disc Retainer - Steel/Stainless Steel - 129228
C477-24 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037
C477-24 Excess Flow Spring - 160 GPM (Blue) - 129213
C477-24 Excess Flow Spring - 265 GPM (Black) - 129214
C477-24 Excess Flow Spring - 375/400 GPM (Yellow) - 129223
C477-24 Excess Flow Spring - 400/460 GPM (Red) - 129216
C477-24 Female Packing Adaptor - Teflon® (PTFE) - 127113
C477-24 P134T Fusible Link - 122640
C477-24 Gland - Steel - 129176
C477-24 Gland Assembly & O-Ring - Nitrile (NBR) - 129186
C477-24 Gland O-Ring - Ethylene Propylene (EPDM) - 129217
C477-24 Gland O-Ring - Nitrile (NBR) - 128697
C477-24 Gland O-Ring - Teflon® (PTFE) - 129030
C477-24 Gland O-Ring - Viton® (FKM) - 125779
C477-24 Guide - Iron - 129500
C477-24 Hex Nut - Plated Steel - 129200
C477-24 Liner Bushing - Teflon® (PTFE) - 128664
C477-24 Liner Bushing - Teflon® (PTFE) - 128682
C477-24 Main Disc - Ethylene Propylene (EPDM) - 129895
C477-24 Main Disc - Kalrez® (FFKM) - 129751
C477-24 Main Disc - Neoprene (CR) - 129106
C477-24 Main Disc - Nitrile (NBR) - 128823
C477-24 Main Disc - Teflon® (PTFE) - 125775
C477-24 Main Disc - Viton® (FKM) - 125871
C477-24 Male Packing Adaptor - Teflon® (PTFE) - 128676
C477-24 Operating Lever - Steel - 128700
C477-24 Packing - Teflon® (PTFE) (Qty. 3) - 128679
C477-24 Repair Kit - 125017
C477-24 Rod Wiper - Polyurethane (PU) - 128685
C477-24 Screw - Stainless Steel (Qty. 6) - 129235
C477-24 Spring - Stainless Steel - 128670
C477-24 Spring Lock Washer - 129321
C477-24 Spring Lock Washer (Qty. 3) - 129322
C477-24 Spring Seat - Stainless Steel - 129220
C477-24 Stem Assembly - Steel/Stainless Steel - 129210
C477-24 Stub Shaft - Stainless Steel - 129189
C477-24 Travel Stop - Stainless Steel - 125860
C477-24 Washer - Stainless Steel - 125801
C477-24 Washer - Stainless Steel - 129035
C477-24 Washer - Stainless Steel - 129038
C477-24 Washer - Stainless Steel (Qty. 2) - 129039
C477-24 Washer - Steel - 128667
C477-24 Washer - Steel (Qty. 2) - 128673
C477-24 Washer - Steel - 128898
