C471-24-375

Item Number120326
  • Connections Inlet X Outlet: 3" MNPT X3" FNPT

  • Closing Flow GPM / l/min Propane * Half Coupling: 375 / 1,419

  • Closing Flow GPM / l/min Propane * Full Coupling: 320 / 1,211

  • Vapor Capacity SCFH / SCMH Propane * 25 psig / 1,7 bar Inlet: 99,000 / 2,803

  • Vapor Capacity SCFH / SCMH Propane * 100 psig / 6,9 bar Inlet: 178,000 / 5,040

C471-24 Air Actuator - 122934

C471-24 Bleed Disc - Ethylene Propylene (EPDM) - 129320

C471-24 Bleed Disc - Kalrez® (FFKM) - 129318

C471-24 Bleed Disc - Neoprene (CR) - 129319

C471-24 Bleed Disc - Nitrile (NBR) - 129412

C471-24 Bleed Disc - Teflon® (PTFE) - 129316

C471-24 Bleed Disc - Viton® (FKM) - 129317

C471-24 Bleed Disc Retainer - Stainless Steel - 129410

C471-24 Bleed Disc Seat - Stainless Steel - 129411

C471-24 Body - Ductile Iron - 129401

C471-24 Bonnet Nut - Steel - 128688

C471-24 Bushing - Teflon® (PTFE) - 125800

C471-24 Cable Latch - 122912

C471-24 Cam - Stainless Steel - 129031

C471-24 Cam - Steel - 128694

C471-24 Cap Screw - Stainless Steel - 129032

C471-24 Cap Screw - Steel - 126282

C471-24 Cap Screw - Steel (Qty. 3) - 129063

C471-24 Closing Spring - Stainless Steel - 128646

C471-24 Cotter Pin - Stainless Steel - 129056

C471-24 Cotter Pin for Lever - 127092

C471-24 Disc Holder - Stainless Steel - 129230

C471-24 Disc Retainer - Steel/Stainless Steel - 129228

C471-24 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037

C471-24 Excess Flow Spring - 160 GPM (Blue) - 129213

C471-24 Excess Flow Spring - 265 GPM (Black) - 129214

C471-24 Excess Flow Spring - 375/400 GPM (Yellow) - 129223

C471-24 Excess Flow Spring - 400/460 GPM (Red) - 129216

C471-24 Female Packing Adaptor - Teflon® (PTFE) - 127113

C471-24 P134T Fusible Link - 122640

C471-24 Gland - Steel - 129176

C471-24 Gland Assembly & O-Ring - Nitrile (NBR) - 129186

C471-24 Gland O-Ring - Ethylene Propylene (EPDM) - 129217

C471-24 Gland O-Ring - Nitrile (NBR) - 128697

C471-24 Gland O-Ring - Teflon® (PTFE) - 129030

C471-24 Gland O-Ring - Viton® (FKM) - 125779

C471-24 Guide - Iron - 129500

C471-24 Hex Nut - Plated Steel - 129200

C471-24 Liner Bushing - Teflon® (PTFE) - 128664

C471-24 Liner Bushing - Teflon® (PTFE) - 128682

C471-24 Main Disc - Ethylene Propylene (EPDM) - 129895

C471-24 Main Disc - Kalrez® (FFKM) - 129751

C471-24 Main Disc - Neoprene (CR) - 129106

C471-24 Main Disc - Nitrile (NBR) - 128823

C471-24 Main Disc - Teflon® (PTFE) - 125775

C471-24 Main Disc - Viton® (FKM) - 125871

C471-24 Male Packing Adaptor - Teflon® (PTFE) - 128676

C471-24 Operating Lever - Steel - 128700

C471-24 Packing - Teflon® (PTFE) (Qty. 3) - 128679

C471-24 Repair Kit - 125017

C471-24 Rod Wiper - Polyurethane (PU) - 128685

C471-24 Screw - Stainless Steel (Qty. 6) - 129235

C471-24 Spring - Stainless Steel - 128670

C471-24 Spring Lock Washer - 129321

C471-24 Spring Lock Washer (Qty. 3) - 129322

C471-24 Spring Seat - Stainless Steel - 129220

C471-24 Stem Assembly - Steel/Stainless Steel - 129210

C471-24 Stub Shaft - Stainless Steel - 129189

C471-24 Travel Stop - Stainless Steel - 125860

C471-24 Washer - Stainless Steel - 125801

C471-24 Washer - Stainless Steel - 129035

C471-24 Washer - Stainless Steel - 129038

C471-24 Washer - Stainless Steel (Qty. 2) - 129039

C471-24 Washer - Steel - 128667

C471-24 Washer - Steel (Qty. 2) - 128673

C471-24 Washer - Steel - 128898
