- Connections Inlet X Outlet: 3” CL300 RF Modified Flange (4 5/8” Dia. Bore) x 3” CL300 RF Flange
- Closing Flow GPM / l/min Propane Top Of Tank Position: 290 / 1,098
- Vapor Capacity SCFH / SCMH Propane Standard Position: 127,000 / 3,568
- Vapor Capacity SCFH / SCMH Propane Inverted Position: 148,000 / 4,191
- Closing Flow GPM / l/min Propane Bottom Of Tank Position: 265 / 1,003
C483-24 Air Actuator - 122933
C483-24 Bleed Disc - Ethylene Propylene (EPDM) - 129320
C483-24 Bleed Disc - Kalrez® (FFKM) - 129318
C483-24 Bleed Disc - Neoprene (CR) - 129319
C483-24 Bleed Disc - Nitrile (NBR) - 129412
C483-24 Bleed Disc - Teflon® (PTFE) - 129316
C483-24 Bleed Disc - Viton® (FKM) - 129317
C483-24 Bleed Disc Retainer - Stainless Steel - 129410
C483-24 Bleed Disc Seat - Stainless Steel - 129411
C483-24 Bolt - 410/416 Stainless Steel (Qty. 2) - 128455
C483-24 Bonnet Nut - Steel - 128688
C483-24 Cam - Steel - 128694
C483-24 Cap Screw - Steel - 129520
C483-24 Cap Screw - Carbon-Plated Steel (Qty. 2) - 129615
C483-24 Closing Spring - Stainless Steel - 128646
C483-24 Cotter Pin - Stainless Steel - 129056
C483-24 Cotter Pin for Lever - 127092
C483-24 Disc Holder - Stainless Steel - 129230
C483-24 Disc Retainer - Steel/Stainless Steel - 129228
C483-24 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037
C483-24 Excess Flow Spring - 160 GPM (Blue) - 129213
C483-24 Excess Flow Spring - 265 GPM (Black) - 129214
C483-24 Excess Flow Spring - 400/460 GPM (Red) - 129216
C483-24 Female Packing Adaptor - Teflon® (PTFE) - 127113
C483-24 P134T Fusible Link - 122640
C483-24 Guide Bracket - Zinc-Plated Steel - 129286
C483-24 Hex Nut - Stainless Steel (Qty. 16) - 129036
C483-24 Liner Bushing - Teflon® (PTFE) - 128664
C483-24 Liner Bushing - Teflon® (PTFE) - 128682
C483-24 Lower Gasket - 127983
C483-24 Main Disc - Ethylene Propylene (EPDM) - 129895
C483-24 Main Disc - Kalrez® (FFKM) - 129751
C483-24 Main Disc - Neoprene (CR) - 129106
C483-24 Main Disc - Nitrile (NBR) - 128823
C483-24 Main Disc - Teflon® (PTFE) - 125775
C483-24 Main Disc - Viton® (FKM) - 125871
C483-24 Male Packing Adaptor - Teflon® (PTFE) - 128676
C483-24 Nut - Carbon-Plated Steel (Qty. 2) - 127295
C483-24 Nut - Carbon-Plated Steel - 129868
C483-24 Operating Lever - Steel - 128700
C483-24 Packing - Teflon® (PTFE) (Qty. 3) - 128679
C483-24 Repair Kit - 125022
C483-24 Rod Wiper - Polyurethane (PU) - 128685
C483-24 Screen - Stainless Steel - 125854
C483-24 Screen Cap - Stainless Steel - 125855
C483-24 Screw - Stainless Steel (Qty. 6) - 129235
C483-24 Spring - Stainless Steel - 128670
C483-24 Spring Lock Washer - 129321
C483-24 Spring Lock Washer (Qty. 3) - 129322
C483-24 Spring Seat - Stainless Steel - 129220
C483-24 Stem Assembly - Steel/Stainless Steel - 129210
C483-24 Stub Shaft - Stainless Steel - 129189
C483-24 Stud Bolt - Stainless Steel (Qty. 16) - 127614
C483-24 Travel Stop - Stainless Steel - 125860
C483-24 Upper Gasket - 129924
C483-24 Washer - Stainless Steel - 125799
C483-24 Washer - Steel - 128667
C483-24 Washer - Steel (Qty. 2) - 128673
C483-24 Washer - Steel - 128898
