Fisher Bleed Discs & Parts
Click on "Item No." or "Part No." for part description and technical info.
Expand Table| Item No | Part No | Type | Fits |
|---|---|---|---|
| 129091 | T13395T0022 | Bleed Disc - Teflon® (PTFE) | C407-10 |
| 128658 | T1154303032 | Bleed Disc - Neoprene (CR) | N/A |
| 128310 | T1116803202 | Bleed Disc - Nitrile (NBR) | C404-32 |
| 129412 | ERAA00328A0 | Bleed Disc - Nitrile (NBR) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129410 | ERAA00324A0 | Bleed Disc Retainer - Stainless Steel | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129411 | ERAA00325A0 | Bleed Disc Seat - Steel/Stainless Steel | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129316 | ERAA00328A1 | Bleed Disc - Teflon® (PTFE) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129319 | ERAA00328A4 | Bleed Disc - Neoprene (CR) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129318 | ERAA00328A3 | Bleed Disc - Kalrez® (FFKM) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129320 | ERAA02202A0 | Bleed Disc - Ethylene Propylene (EPDM) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129877 | T13395T0012 | Bleed Disc - Nitrile (NBR) | C407-10 |
| 129867 | T13406T0012 | Bleed Seat - 303 SST | C407-10 |
| 129508 | T12514T0012 | Bleed Disc - Viton® (FKM) | C404-32 |
| 128790 | T1171506242 | Bleed Disc - Teflon® (PTFE) | C404-32 |
| 129317 | ERAA00328A2 | Bleed Disc - Viton® (FKM) | C471-16, C471-24, C477-16, C477-24, C483-24, C484-24, & C486-24 |
| 129098 | T13395T0032 | Bleed Disc - Viton® (FKM) | C407-10 |
| 128280 | T11543T0012 | Bleed Disc - Nitrile (NBR) | N/A |
