- Type: Rebuild Kit
- Fits: Z3500
| 3196-X16 Rebuild Kit Contents |
||
| Part Number | Description | Quantity |
| 2-228A | O-Ring - Buna N | 2 |
| 2754-X | Roller Bearing | 2 |
| 5557-X | Vane Driver | 6 |
| 3936 | Vane | 6 |
| 6660-XA6 | Seal Assembly | 2 |
| 4432 | Thrust Bearing | 2 |
| 4435 | Thrust Bearing Mounting Ring | 2 |
| 4439 | Bearing Cap Shim (0.002") | 8 |
| 4439-1 | Bearing Cap Shim (0.010") | 2 |
| 4439-2 | Bearing Cap Shim (0.020") | 2 |
| 4441 | Grease Seal | 2 |
| 2270 | Shaft Key | 1 |
| 5539 | Cam | 1 |
| 3935 | Sideplate | 2 |
All repair kits are furnished with Buna-N O-rings which are suitable for LP-Gas or NH3 applications.
