- Flow Capacity - SCFM Air U.L. @ 120% Set Pressure: -----
- Tank Connection: 3/4" MNPT
- Relief Setting: 375 PSIG
Designed for installation in stationary ASME applications such as bulk plant, skid tanks, underground and above ground containers, as the primary pressure relief valve.
NOTE: This valve and all working parts are to be installed outside the container. Therefore, to ensure proper operation of the valve, the valve must be protected from damage and inspections performed as prescribed by Marshall Excelsior.
Features:
• Compact design to fit any application.
• Stainless steel spring.
• Non-adjustable, tamper resistant design.
• Specially designed internal components to increase flow at discharge.
Pipeaway Adaptor - 150859
