Fisher Hydrostatic Relief Valves
Click on "Item No." or "Part No." for part description and technical info.
Expand Table| Item No | Part No | Tank Connection | Relief Setting | Flow Capacity - SCFM Air |
|---|---|---|---|---|
| 120907 | H120-60 | 1/4" MNPT | 60 PSIG | 105 |
| 120908 | H120-120 | 1/4" MNPT | 120 PSIG | 165 |
| 120906 | H120-150 | 1/4" MNPT | 150 PSIG | 191 |
| 120912 | H120-175 | 1/4" MNPT | 175 PSIG | 224 |
| 120909 | H120-225 | 1/4" MNPT | 225 PSIG | 280 |
| 120902 | H120-275 | 1/4" MNPT | 275 PSIG | 303 |
| 120910 | H123 | 1/4" MNPT | 375 PSIG | ----- |
| 120915 | H124 | 1/4" MNPT | 450 PSIG | ----- |
| 120927 | H144 | 1/2" MNPT | 450 PSIG | ----- |
| 120930 | H148 | 1/2" MNPT | 375 PSIG | 903 |
| 120945 | H173 | 3/4" MNPT | 375 PSIG | 903 |
| 120947 | H174 | 3/4" MNPT | 450 PSIG | ----- |
