MEC Backpressure Regulator/Relief Valves - Vapor
Click on "Item No." or "Part No." for part description and technical info.
Expand Table| Item No | Part No | Inlet/Outlet | Max. Inlet PSIG | Set Point | Set Point Range | SCFH / Propane |
|---|---|---|---|---|---|---|
| 151120 | MEGR-1289H/1 | 2" FNPT | 25 | 9" WC | 7-18" WC | 55,000 |
| 151122 | MEGR-1289H/2 | 2" FNPT | 25 | 1 PSIG | .5-2.25 PSIG | 55,000 |
| 151124 | MEGR-1289H/3 | 2" FNPT | 25 | 3 PSIG | 1.75-7 PSIG | 58,000 |
| 151128 | MEGR-1289H/41 | 1" FNPT | 100 | 2 PSIG | 1-4.5 PSIG | 45,500 |
| 151130 | MEGR-1289H/42 | 1" FNPT | 100 | 8 PSIG | 4-15 PSIG | 46,000 |
| 151132 | MEGR-1289H/43 | 1" FNPT | 100 | 15 PSIG | 10-20 PSIG | 48,000 |
| 151136 | MEGR-1289HH-1 | 1" FNPT | 100 | 50 PSIG | 45-75 PSIG | 50,000 |
