- Inlet: 2" FNPT
- Outlet: 2" FNPT
- LP-Gas Flow Rate: 40-85 GPM
- NH3 Flow Rate: 37-75 GPM
Shaft Size: 1 1/8"
Max. RPM: 750
Seal Replacement @ 3:30
Complete Rebuild @ 11:45
Z2000 With Base - 140187
Z2000 Bearing Cap (Qty. 2) - 145001
Z2000 Bearing Cap Shim (.002") Red (Qty. As Req.) - 140502
Z2000 Bearing Cap Shim (.010") Brown (Qty. As Req.) - 140356
Z2000 Bearing Cap Shim (.020") Yellow (Qty. As Req.) - 140503
Z2000 Bearing Race Mounting Ring (Qty. 2) - 140501
Z2000 Cam - 145004
Z2000 Cam Key Pin (Qty. 2) - 140708
Z2000 Case O-Ring - Buna-N (Qty. 2) - 140950
Z2000 Flange O-Ring - Buna-N (Qty. 2) - 140970
Z2000 Grease Seal (Qty. 2) - 140511
Z2000 Grease Zerk - 1/8" NPT (Qty. 2) - 140862
Z2000 Hex Head Bolt - 3/8-16 X 1 1/2" (Qty. 16) - 140546
Z2000 Hex Head Bolt (Qty. 16) - 140524
Z2000 Lubricap (Qty. 2) - 140817
Z2000 Oil Seal (Qty. 2) - 140787
Z2000 O-Ring - Buna-N - 140938
Z2000 O-Ring - Teflon® - 140965
Z2000 Relief Fitting - 1/8" NPT (Qty. 4) - 140725
Z2000 Relief Valve Shim - 140355
Z2000 Relief Valve Spring - 140712
Z2000 Repair Kit - 140195
Z2000 Retainer Ring (Qty. 2) - 140854
Z2000 Roller Bearing - Complete (Qty. 2) - 140850
Z2000 Rotor & Shaft Assembly - 140181
Z2000 Seal Assembly (Qty. 2) - 140201
Z2000 Shaft Key - 1/4" X 1 9/16" (Qty. 2) - 140813
Z2000 Sideplate (Qty. 2) - 140190
Z2000 Thrust Bearing Assembly (Qty. 2) - 140500
Z2000 Vane (Qty. 6) - 145006
Z2000 Vane Driver (Qty. 3) - 140352
