- Connections Inlet X Outlet: 3” CL300 RF Modified Flange (4 5/8” Dia. Bore) x 3” CL300 RF Flange
- Closing Flow GPM / l/min Propane Top Of Tank Position: 250 / 946
- Vapor Capacity SCFH / SCMH Propane Standard Position: Not Listed
- Vapor Capacity SCFH / SCMH Propane Inverted Position: Not Listed
- Closing Flow GPM / l/min Propane Bottom Of Tank Position: 250 / 946
C484-24 Air Actuator - 122936
C484-24 Bleed Disc - Ethylene Propylene (EPDM) - 129320
C484-24 Bleed Disc - Kalrez® (FFKM) - 129318
C484-24 Bleed Disc - Neoprene (CR) - 129319
C484-24 Bleed Disc - Nitrile (NBR) - 129412
C484-24 Bleed Disc - Teflon® (PTFE) - 129316
C484-24 Bleed Disc - Viton® (FKM) - 129317
C484-24 Bleed Disc Retainer - Stainless Steel - 129410
C484-24 Bleed Disc Seat - Stainless Steel - 129411
C484-24 Bonnet Nut - Steel - 128688
C484-24 Bushing - Teflon® (PTFE) - 129221
C484-24 Cam - Steel - 128694
C484-24 Cap Screw - Carbon-Plated Steel (Qty. 4) - 129612
C484-24 Cap Screw - Carbon-Plated Steel - 129615
C484-24 Cap Screw - Steel - 126282
C484-24 Closing Spring - Stainless Steel - 128646
C484-24 Cotter Pin - Stainless Steel - 129056
C484-24 Cotter Pin for Lever - 127092
C484-24 Disc Holder - Stainless Steel - 129230
C484-24 Disc Retainer - Steel/Stainless Steel - 129228
C484-24 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037
C484-24 Excess Flow Spring - 160 GPM (Blue) - 129213
C484-24 Excess Flow Spring - 250 GPM (Orange) - 128922
C484-24 Excess Flow Spring - 375/400 GPM (Yellow) - 129223
C484-24 Female Packing Adaptor - Teflon® (PTFE) - 127113
C484-24 P134T Fusible Link - 122640
C484-24 Hex Nut - Stainless Steel (Qty. 16) - 129036
C484-24 Liner Bushing - Teflon® (PTFE) - 128682
C484-24 Lower Gasket - 127764
C484-24 Main Disc - Ethylene Propylene (EPDM) - 129895
C484-24 Main Disc - Kalrez® (FFKM) - 129751
C484-24 Main Disc - Neoprene (CR) - 129106
C484-24 Main Disc - Nitrile (NBR) - 128823
C484-24 Main Disc - Teflon® (PTFE) - 125775
C484-24 Main Disc - Viton® (FKM) - 125871
C484-24 Male Packing Adaptor - Teflon® (PTFE) - 128676
C484-24 Nut - 303 Stainless Steel - 129599
C484-24 Operating Lever - Steel - 128700
C484-24 Packing - Teflon® (PTFE) (Qty. 3) - 128679
C484-24 Repair Kit - 125023
C484-24 Rod Wiper - Polyurethane (PU) - 128685
C484-24 Screen - Stainless Steel - 125854
C484-24 Screen Cap - Stainless Steel - 125853
C484-24 Screw - Stainless Steel (Qty. 6) - 129235
C484-24 Spring - Stainless Steel - 128670
C484-24 Spring Lock Washer - 129321
C484-24 Spring Lock Washer (Qty. 3) - 129322
C484-24 Stem Assembly - Steel/Stainless Steel - 129210
C484-24 Stub Shaft - Stainless Steel - 129189
C484-24 Stud Bolt - Zinc-Plated Steel (Qty. 8) - 127743
C484-24 Travel Stop - Stainless Steel - 125860
C484-24 Upper Gasket - 129924
C484-24 Washer - Stainless Steel - 125799
C484-24 Washer - Steel - 128667
C484-24 Washer - Steel (Qty. 2) - 128673
C484-24 Washer - Steel - 128898
