- Connections Inlet X Outlet: 2" MNPT X2" FNPT
- Closing Flow GPM / l/min Propane * Half Coupling: 250 / 946
- Closing Flow GPM / l/min Propane * Full Coupling: 130 / 492
- Vapor Capacity SCFH / SCMH Propane * 25 psig / 1,7 bar Inlet: -----
- Vapor Capacity SCFH / SCMH Propane * 100 psig / 6,9 bar Inlet: -----
C477-16 Air Actuator - 122934
C477-16 Bleed Disc - Ethylene Propylene (EPDM) - 129320
C477-16 Bleed Disc - Kalrez® (FFKM) - 129318
C477-16 Bleed Disc - Neoprene (CR) - 129319
C477-16 Bleed Disc - Nitrile (NBR) - 129412
C477-16 Bleed Disc - Teflon® (PTFE) - 129316
C477-16 Bleed Disc - Viton® (FKM) - 129317
C477-16 Bleed Disc Retainer - Stainless Steel - 129410
C477-16 Bleed Disc Seat - Stainless Steel - 129411
C477-16 Body - Ductile Iron - 129400
C477-16 Bonnet Nut - Steel - 128688
C477-16 Bushing - Teflon® (PTFE) - 125800
C477-16 Cable Latch - 122912
C477-16 Cam - Stainless Steel - 129031
C477-16 Cam - Steel - 128694
C477-16 Cap Screw - Stainless Steel - 129032
C477-16 Cap Screw - Steel - 126282
C477-16 Cap Screw - Steel (Qty. 3) - 129063
C477-16 Closing Spring - Stainless Steel - 128646
C477-16 Cotter Pin - Stainless Steel - 129056
C477-16 Cotter Pin for Lever - 127092
C477-16 Disc Holder - Stainless Steel - 129229
C477-16 Disc Retainer - Steel/Stainless Steel - 129227
C477-16 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037
C477-16 Excess Flow Spring - 105 GPM (Green) - 129209
C477-16 Excess Flow Spring - 150 GPM (Yellow) - 128640
C477-16 Excess Flow Spring - 250 GPM (Pink) - 128967
C477-16 Female Packing Adaptor - Teflon® (PTFE) - 127113
C477-16 P134T Fusible Link - 122640
C477-16 Gland - Steel - 129176
C477-16 Gland Assembly & O-Ring - Nitrile (NBR) - 129171
C477-16 Gland O-Ring - Nitrile (NBR) - 128697
C477-16 Guide - Iron - 129750
C477-16 Hex Nut - Plated Steel - 129200
C477-16 Liner Bushing - Teflon® (PTFE) - 128664
C477-16 Liner Bushing - Teflon® (PTFE) - 128682
C477-16 Main Disc - Ethylene Propylene (EPDM) - 129893
C477-16 Main Disc - Kalrez® (FFKM) - 129036
C477-16 Main Disc - Neoprene (CR) - 129105
C477-16 Main Disc - Nitrile (NBR) - 128649
C477-16 Main Disc - Teflon® (PTFE) - 129024
C477-16 Main Disc - Viton® (FKM) - 125869
C477-16 Male Packing Adaptor - Teflon® (PTFE) - 128676
C477-16 Operating Lever - Steel - 128700
C477-16 O-Ring - Ethylene Propylene (EPDM) - 129217
C477-16 O-Ring - Teflon® (PTFE) - 129030
C477-16 O-Ring - Viton® (FKM) - 125779
C477-16 Packing - Teflon (PTFE) (Qty. 3) - 128679
C477-16 Repair Kit - 125012
C477-16 Rod Wiper - Polyurethane (PU) - 128685
C477-16 Screw - Stainless Steel (Qty. 4) - 129235
C477-16 Spring - Stainless Steel - 128670
C477-16 Spring Lock Washer - 129321
C477-16 Spring Lock Washer (Qty. 3) - 129322
C477-16 Spring Seat - Stainless Steel - 129201
C477-16 Stem Assembly - Steel/Stainless Steel - 129205
C477-16 Stub Shaft - Stainless Steel - 129174
C477-16 Travel Stop - Stainless Steel - 125860
C477-16 Washer - Stainless Steel - 125801
C477-16 Washer - Stainless Steel - 129035
C477-16 Washer - Stainless Steel - 129038
C477-16 Washer - Stainless Steel (Qty. 2) - 129039
C477-16 Washer - Steel - 128667
C477-16 Washer - Steel (Qty. 2) - 128673
C477-16 Washer - Steel - 128898
