- Connections Inlet X Outlet: 2" MNPT X2" FNPT
- Closing Flow GPM / l/min Propane * Half Coupling: 250 / 946
- Closing Flow GPM / l/min Propane * Full Coupling: 130 / 492
- Vapor Capacity SCFH / SCMH Propane * 25 psig / 1,7 bar Inlet: -----
- Vapor Capacity SCFH / SCMH Propane * 100 psig / 6,9 bar Inlet: -----
C471-16 Air Actuator - 122934
C471-16 Bleed Disc - Ethylene Propylene (EPDM) - 129320
C471-16 Bleed Disc - Kalrez® (FFKM) - 129318
C471-16 Bleed Disc - Neoprene (CR) - 129319
C471-16 Bleed Disc - Nitrile (NBR) - 129412
C471-16 Bleed Disc - Teflon® (PTFE) - 129316
C471-16 Bleed Disc - Viton® (FKM) - 129317
C471-16 Bleed Disc Retainer - Stainless Steel - 129410
C471-16 Bleed Disc Seat - Stainless Steel - 129411
C471-16 Bonnet Nut - Steel - 128688
C471-16 Bushing - Teflon® (PTFE) - 125800
C471-16 Cable Latch - 122912
C471-16 Cam - Stainless Steel - 129031
C471-16 Cam - Steel - 128694
C471-16 Cap Screw - Stainless Steel - 129032
C471-16 Cap Screw - Steel - 126282
C471-16 Cap Screw - Steel (Qty. 3) - 129063
C471-16 Closing Spring - Stainless Steel - 128646
C471-16 Cotter Pin - Stainless Steel - 129056
C471-16 Cotter Pin for Lever - 127092
C471-16 Disc Holder - Stainless Steel - 129229
C471-16 Disc Retainer - Steel/Stainless Steel - 129227
C471-16 Drive Screw - 18-8 Stainless Steel (Qty. 2) - 126037
C471-16 Excess Flow Spring - 105 GPM (Green) - 129209
C471-16 Excess Flow Spring - 150 GPM (Yellow) - 128640
C471-16 Excess Flow Spring - 250 GPM (Pink) - 128967
C471-16 Female Packing Adaptor - Teflon® (PTFE) - 127113
C471-16 P134T Fusible Link - 122640
C471-16 Gland - Steel - 129176
C471-16 Gland Assembly & O-Ring - Nitrile (NBR) - 129171
C471-16 Gland O-Ring - Nitrile (NBR) - 128697
C471-16 Guide - Iron - 129750
C471-16 Hex Nut - Plated Steel - 129200
C471-16 Liner Bushing - Teflon® (PTFE) - 128664
C471-16 Liner Bushing - Teflon® (PTFE) - 128682
C471-16 Main Disc - Ethylene Propylene (EPDM) - 129893
C471-16 Main Disc - Kalrez® (FFKM) - 129036
C471-16 Main Disc - Neoprene (CR) - 129105
C471-16 Main Disc - Nitrile (NBR) - 128649
C471-16 Main Disc - Teflon® (PTFE) - 129024
C471-16 Main Disc - Viton® (FKM) - 125869
C471-16 Male Packing Adaptor - Teflon® (PTFE) - 128676
C471-16 Operating Lever - Steel - 128700
C471-16 O-Ring - Ethylene Propylene (EPDM) - 129217
C471-16 O-Ring - Teflon® (PTFE) - 129030
C471-16 O-Ring - Viton® (FKM) - 125779
C471-16 Packing - Teflon® (PTFE) (Qty. 3) - 128679
C471-16 Repair Kit - 125012
C471-16 Rod Wiper - Polyurethane (PU) - 128685
C471-16 Screw - Stainless Steel (Qty. 4) - 129235
C471-16 Spring - Stainless Steel - 128670
C471-16 Spring Lock Washer - 129321
C471-16 Spring Lock Washer (Qty. 3) - 129322
C471-16 Spring Seat - Stainless Steel - 129201
C471-16 Stem Assembly - Steel/Stainless Steel - 129205
C471-16 Stub Shaft - Stainless Steel - 129174
C471-16 Travel Stop - Stainless Steel - 125860
C471-16 Washer - Stainless Steel - 125801
C471-16 Washer - Stainless Steel - 129035
C471-16 Washer - Stainless Steel - 129038
C471-16 Washer - Stainless Steel (Qty. 2) - 129039
C471-16 Washer - Steel - 128667
C471-16 Washer - Steel (Qty. 2) - 128673
C471-16 Washer - Steel - 128898
